Plaub:
1. Qhov kub thiab txias: hom Piezoelectric: -25 ℃ + +350 ℃ hom peev xim: -40 ～ ～ 50450 ℃
2. Cov qauv sib txuas: DN15 ～ DN300 yog flange-mounted lossis flange kev sib txuas hom, DN300 ～ DN1000 yog plug-in hom, thiab DN1000 thiab sab saum toj tuaj yeem tshwj xeeb xaj
3. Cov nqi ntws ntau: chav haujlwm: 7m / s ～ 70m / s kua: 0.7m / s ～ 7m / s roj: 5 ～ 35m / s
4. Siab cov lus qhia: PN1.6MPa; PN2.5MPa; PN4.0MPa, kev kub siab dua yuav tsum muab kho kom haum
5. Lub zog poob coefficient: Cd≤2.6
6. Qhov tseeb: flange daim npav mounting hom, flange kev sib txuas hom: 0.5, 1.0, 1.5 ntsaws hom: 1.5, 2.5
7. Cov ntsuas hluav taws xob: Cov Sensor: DC12V lossis DC24V, Cov Khoom Hloov Hloov: DC24V
Cov khoom teeb pom kev zoo sab hauv: DC24V, DC12V lossis 3.6V lithium roj teeb
8. tawm cov phiajcim: Sensor: mem tes zaus teeb liab 2 ～ 3000Hz, qis level≤1V, qib siab -6V, kis tau: ob-xaim system 4 ～ 20mA.DC cov teeb liab tam sim no
9. Kev ua haujlwm Seismic: piezoelectric hom ≤0.2g muaj peev xwm hom ≤2.0g
10. Kev kub ntxhov nyob ib puag ncig: Tus ntsuas pa: -30 ℃ ～ +65 ℃ Transmitter: teeb pom ntawm-10 ℃ ～ +50 ℃
11. Qhov chaw noo noo: txheeb ze cua noo 5 ～ 85% RH
12. Lub teeb liab kis tau teeb meem deb: ≤500m
13. Cov yeeb nkab ncaj ncaj: upstream≥10D downstream≥5D
14. Tawg-pov thawj qib: Exia IICT2-T5 kev tso tshuaj pov thawj tawg-pov thawj
15. Qib kev tiv thaiv: cov hom IP65, submersible hom IP68
16. Cov khoom siv los ntsuas: Lub plhaub ntsuas yog ua los ntawm aluminium alloy, thiab lub cev lub cev yog ua los ntawm cov hlau tsis xeb 304. Cov khoom siv tshwj xeeb kuj tseem siv tau raws li cov neeg siv xav tau.
Ntws ntau
| specification | Ua kua ntws ntau （m³ / h） | Roj zoo tib yam ntws ntau （m³ / h） | ||
Qmin | Qmax | Qmin | Qmax | |
DN15 | 0.3 | 3 | 3 | 30 |
DN20 | 0.6 | 6 | 6 | 60 |
DN25 | 1.0 | 12 | 10 | 120 |
DN32 | 1.2 | 15 | 12 | 180 |
DN40 | 1.5 | 31 | 15 | 275 |
DN50 | 2.2 | 49 | 25 | 458 |
DN65 | 3.6 | 84 | 40 | 730 |
DN80 | 5.5 | 127 | 55 | 1008 |
DN100 | 8.5 | 198 | 85 | 1550 |
DN125 | 13.3 | 309 | 140 | 2566 |
DN150 | 19.1 | 445 | 190 | 3483 |
DN200 | 34 | 790 | 340 | 6230 |
DN250 | 70 | 900 | 700 | 9000 |
DN300 | 130 | 2100 | 1200 | 21000 |
DN350 | 180 | 2500 | 1500 | 25000 |
DN400 | 230 | 3400 | 2000 | 34000 |
Cov FAQ
1.How txog koj lub sijhawm khoom xa tuaj?
Feem ntau, nws yuav siv li 5 mus rau 10 hnub tom qab tau txais koj cov nyiaj them ua ntej. Lub sijhawm thauj khoom tshwj xeeb yog nyob ntawm cov khoom thiab qhov ntau ntawm koj cov xaj.
2.What yog lub lav rau koj cov khoom?
Warranty: 1 xyoos.
3.What yog lub warranty rau koj cov khoom?
Warranty: 1 xyoos.
4. Koj tuaj yeem ua khoom raws li cov qauv?
Yog lawm, peb tuaj yeem tsim los ntawm koj cov qauv lossis cov qauv kos duab. Peb tuaj yeem tsim cov pwm thiab cov cuab yeej ua tiav.
5.Qhov koj txoj kev them nqi yog dab tsi?
Paypal, T / T, L / C, Cov Pabcuam Western, muaj.
6.How koj ntim koj cov khoom?
Peb ntim cov khoom muag hauv rooj ntoo lossis raws li cov neeg siv' s yuav tsum tau ua.
7.What yog lub lav rau koj cov khoom?
Warranty: 1 xyoos.
